Calculate the time for the safety timer as follows:
Examples:
Battery capacity Charging current Timer time
2000 mAh 2.0 A 2000 / 2.0 = 1000 / 11.9 = 84 minutes
3300 mAh 3.0 A 3300 / 3.0 = 1100 / 11.9 = 92 minutes
1000 mAh 1.2 A 1000 / 1.2 = 833 / 11.9 = 70 minutes
The factor 11.9 is used to permit charging 140% of the rechargeable battery capacity (the rechargeable bat-
tery is guaranteed to be fully charged then), before the safety timer trips.
Automatic deactivation at specic charging capacity
This safety function of the charger terminates charging automatically when a certain capacity has been "loaded" into
the battery.
The safety function can be switched on ("ON") or off ("OFF") and the capacity can be set.
However, do not set a capacity which is too low; otherwise the rechargeable battery cannot be fully charged.
Switching the key conrmation/warning sounds on/off
With the option "Key Beep", conrmation beep for each push of a button is switched on ("ON") or off ("OFF").
The function "Buzzer" switches the signal sound for various functions/warning messages on ("ON") or off ("OFF").
Monitoring of the input voltage
This function monitors the voltage at the charger input. This is sensible when a 12 V car lead battery is used for
power supply.
If the voltage drops below the set value, charging is terminated to prevent deep discharge of the car lead battery.
Key Beep ON
Buzzer ON
Capacity Cut-Off
ON 5000mAh
Input Power Low
Cut-Off 11.0V
