VOLTCRAFT VSP 2206 - Technical Data

38
Technical Data
VSP 2206 VSP 2403 VSP 2405 VSP 2410 VSP 2653
Output power 249 VA 249 VA 409 VA 809 VA 399 VA
Output voltage 0.1 - 20 V 0.1 - 40 V 0.1 - 40 V 0.1 - 40 V 0.1 - 65 V
DC-Output A
Output current 0 - 6 A 0 - 3 A 0 - 5 A 0 - 10 A 0 - 3 A
Output A
Output voltage 0.1 - 20 V 0.1 - 40 V 0.1 - 40 V 0.1 - 40 V 0.1 - 65 V
DC-Output B
Output current 0 - 6 A 0 - 3 A 0 - 5 A 0 - 10 A 0 - 3 A
Output B
Output voltage
0.1 - 6 V
DC-Output C
Output current
max. 1.5 A
Output C
Residual ripple
at nominal load
Output A of Vmax < 0,025% < 0,025% < 0,0125% < 0,025% < 0,0125%
Output B of Vmax < 0,025% < 0,025% < 0,0125% < 0,025% < 0,0125%
Output C of Vmax < 0,005% < 0,005% < 0,005% < 0,006% < 0,005%
Voltage < 0,04% < 0,04% < 0,03% < 0,04% < 0,03%
Control response at (Vmax) (Vmax) (Vmax) (Vmax) (Vmax)
100% Load change
Voltage < 0,005% < 0,005% < 0,0025% < 0,005% < 0,0025%
Control response at (Vmax) (Vmax) (Vmax) (Vmax) (Vmax)
20% Mains fluctuation
Current control behaviour <5 mA <6 mA <6 mA <5 mA <5 mA
at 100% Load change
Current control behaviour <5 mA <6 mA <6 mA <5 mA < 5 mA
at 20% mains fluctuation
Operating Voltage 230 V/AC (±20%) 47 - 53 Hz
Power consumption 350 VA 350 VA 500 VA 1000 VA 500 VA
(max.)
Mains fuse T2.5A/250V T2.5A/250V T3,15A/250V T6.3A/250V T3.15A/250V
slow-blow (5 x 20 mm)
Operating temperature 0 to +40°C
