27
Repair - MS2 reverse gear and upper gear housing, sailboat drive
884726
884143
884728
9991801
31. Drive or press the input shaft out of the bearing
housing. Use a plastic-faced mallet or similar, to avoid
damaging the end of the shaft and the splines.
32. If the roller bearings are damaged, they must be
changed. Remove the large outer bearing race from
the bearing housing, using tool no. 884726 and shaft
884143.
33. Drive out the small outer bearing race, using tool
884728 and shaft 9991801.
NOTE! Be careful to offer up the tool against the bear-
ing race.
34. Remove the roller bearing from the input shaft, us-
ing a knife-type extractor. Then remove the washer.
Clean the components and check for wear, replace
worn and damaged components.
