33
Repair - MS2 reverse gear and upper gear housing, sailboat drive
55. Remove the seal ring. Use a screwdriver or similar
tool.
NOTE! Use rubber or leather to protect the edges of
the bearing housing.
Clean off all traces of sealant.
54. Press the output shaft out of the bearing housing.
Use tool no. 884730.
57. Remove the ferrule (1) from the output shaft.
884730
1
2
1
56. Remove the O-ring (1) and ball bearing (2) from
the bearing housing.
