62
Repair - lower gear housing, sailboat drive
5. Remove the zinc ring.
3858852
884264
884830
6. Remove the two socket cap screws in the bearing
housing.
7. Remove the propeller shaft and bearing housing.
Use slide hammer 884161 and extractor 884611.
8. Lock the pinion nut with tool no. 3858852. Press
the shaft down and make sure that the pinion nut en-
gages in the tool. Fix the tool to the rear bearing hous-
ing, using socket cap screws.
9. Install tool 884264 or 884830 on the vertical shaft.
Unscrew the pinion nut.
Remove the pinion. If the pinion has got stuck, it will
come loose when the shaft is pressed out later on, in
item 11.
884161
884611
