Technical specifications
Technical specifications
This information is based on the standard bus build. Deviations depending on customer adaptions can occur.
For more information, see the type plate in the bus.
Overall dimensions
A Overall length (mm) 13 690
Overall width (mm) 2 600
B Bogie (mm) 1 400
C Overall height, with AC (mm) 3 671
D Wheelbase (mm) 6 660
G Front overhang (mm) 2 850
H Rear overhang (mm) 2 780
10
Technical data
