Volvo D13J - Engine Overview, D13 J Right Side View

34VOLVOEngines
EngineOverview,D13JRightSideView
W2006035
D13JEngine
Note:Illustrationisusedforreferenceonly
andmaydiffersslightlyfromtheactual
vehicle.
17.ExhaustManifold24.V enturiPipe
18.V alveCover25.OilFilters
19.IntakeAirHeater(IAH)optional26.OilPan
20.Thermostat27.EGRCooler
21.BeltTensioner28.Turbocharger
22.CoolantPump
29.StarterMotor
23.CoolantFilter30.EGRV alve
