7 Ripper tooth: Knock down the locking device
further with a hammer and the tool or other
suitable drift until the upper part is just below the
shown line in the hole and is engaged.
NOTE!
Replace the steel pin in connection with
replacement of tooth adapter.
Locking device in ripper tooth
Maintenance
Maintenance service, when required
175
