Volvo EC60E - Page 329

H
1 m 2 m 3 m 4 m 5 m Max. Reach
Max.
kg kg kg kg kg kg kg kg kg kg kg kg m
Boom: 3.0 m
Dipper arm: 1.9 m
Shoe: 400 mm (Rubber
track)
Counterweight: 440 kg
Dozer blade: Down
5 m - - - - - - - - - - *1380 1290 3.71
4 m - - - - - - *1280 1160 - - *1160 880 4.68
3 m - - - - - - *1360 1140 *1310 780 *1090 720 5.24
2 m - - - - *2070 1700 *1600 1090 *1380 760 *1090 650 5.52
1 m - - - - *2740 1560 *1870 1030 *1480 740 *1140 620 5.58
0 m - - *1510 *1510 *3020 1480 *2030 980 *1530 720 *1270 630 5.43
-1 m *2060 *2060 *2880 2840 *2890 1450 *1980 960 *1380 710 *1350 700 5.05
-2 m *3400 *3400 *3700 2890 *2370 1470 *1590 980 - - *1300 870 4.35
-3 m - - *1690 *1690 *1040 *1040 - - - - *970 *970 3.07
Boom: 3.0 m
Dipper arm: 1.9 m
Shoe: 400 mm (Rubber
track)
Counterweight: 440 kg
Dozer blade: Up
5 m - - - - - - - - - - *1380 1200 3.71
4 m - - - - - - *1280 1080 - - 1130 810 4.68
3 m - - - - - - *1360 1060 1020 730 940 670 5.24
2 m - - - - *2070 1570 1410 1010 1000 710 850 600 5.52
1 m - - - - 2080 1430 1350 950 970 680 820 570 5.58
0 m - - *1510 *1510 2000 1360 1300 910 940 660 840 590 5.43
-1 m *2060 *2060 *2880 2560 1970 1330 1280 890 940 660 930 650 5.05
-2 m *3400 *3400 *3700 2610 1990 1350 1300 900 - - 1160 810 4.35
-3 m - - *1690 *1690 *1040 *1040 - - - - *970 *970 3.07
Boom: 3.0 m
Dipper arm: 1.9 m
Shoe: 380 mm (Steel
track)
Counterweight: 440 kg
Dozer blade: Down
5 m - - - - - - - - - - *1380 1320 3.71
4 m - - - - - - *1280 1190 - - *1160 900 4.68
3 m - - - - - - *1360 1170 *1310 800 *1090 740 5.24
2 m - - - - *2070 1740 *1600 1110 *1380 790 *1090 660 5.52
1 m - - - - *2740 1600 *1870 1050 *1480 760 *1140 640 5.58
0 m - - *1510 *1510 *3020 1520 *2030 1010 *1530 740 *1270 650 5.43
-1 m *2060 *2060 *2880 *2880 *2890 1500 *1980 990 *1380 730 *1350 720 5.05
-2 m *3400 *3400 *3700 2970 *2370 1510 *1590 1000 - - *1300 900 4.35
-3 m - - *1690 *1690 *1040 *1040 - - - - *970 *970 3.07
Boom: 3.0 m
Dipper arm: 1.9 m
Shoe: 380 mm (Steel
track)
Counterweight: 440 kg
Dozer blade: Up
5 m - - - - - - - - - - *1380 1230 3.71
4 m - - - - - - *1280 1110 - - *1160 840 4.68
3 m - - - - - - *1360 1090 1050 750 960 690 5.24
2 m - - - - *2070 1610 1450 1040 1030 730 870 620 5.52
1 m - - - - 2140 1470 1390 980 1000 700 840 590 5.58
0 m - - *1510 *1510 2060 1390 1340 930 980 680 870 600 5.43
-1 m *2060 *2060 *2880 2640 2040 1370 1320 910 970 680 960 670 5.05
-2 m *3400 *3400 *3700 2690 2050 1390 1340 930 - - 1190 830 4.35
-3 m - - *1690 *1690 *1040 *1040 - - - - *970 *970 3.07
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
2. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
3. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
