H
1 m 2 m 3 m 4 m 5 m Max. Reach
Max.
kg kg kg kg kg kg kg kg kg kg kg kg m
Boom: 3.0 m
Dipper arm: 1.9 m
Shoe: 500 mm (Steel
track)
Counterweight: 440 kg
Dozer blade: Down
5 m - - - - - - - - - - *1380 1340 3.71
4 m - - - - - - *1280 1210 - - *1160 920 4.68
3 m - - - - - - *1360 1190 *1310 820 *1090 750 5.24
2 m - - - - *2070 1770 *1600 1140 *1380 800 *1090 680 5.52
1 m - - - - *2740 1630 *1870 1080 *1480 770 *1140 650 5.58
0 m - - *1510 *1510 *3020 1550 *2030 1030 *1530 750 *1270 670 5.43
-1 m *2060 *2060 *2880 *2880 *2890 1530 *1980 1010 *1380 750 *1350 740 5.05
-2 m *3400 *3400 *3700 3030 *2370 1550 *1590 1030 - - *1300 920 4.35
-3 m - - *1690 *1690 *1040 *1040 - - - - *970 *970 3.07
Boom: 3.0 m
Dipper arm: 1.9 m
Shoe: 500 mm (Steel
track)
Counterweight: 440 kg
Dozer blade: Up
5 m - - - - - - - - - - *1380 1250 3.71
4 m - - - - - - *1280 1130 - - *1160 850 4.68
3 m - - - - - - *1360 1110 1070 760 990 700 5.24
2 m - - - - *2070 1640 1480 1060 1050 740 890 630 5.52
1 m - - - - 2190 1500 1420 1000 1020 720 860 600 5.58
0 m - - *1510 *1510 2100 1420 1370 950 1000 700 890 620 5.43
-1 m *2060 *2060 *2880 2690 2080 1400 1350 930 990 690 980 680 5.05
-2 m *3400 *3400 *3700 2740 2100 1420 1370 950 - - 1220 850 4.35
-3 m - - *1690 *1690 *1040 *1040 - - - - *970 *970 3.07
Boom: 3.0 m
Dipper arm: 1.9 m
Shoe: 400 mm (Rubber
pad)
Counterweight: 440 kg
Dozer blade: Down
5 m - - - - - - - - - - *1380 1330 3.71
4 m - - - - - - *1280 1200 - - *1160 910 4.68
3 m - - - - - - *1360 1180 *1310 820 *1090 750 5.24
2 m - - - - *2070 1760 *1600 1130 *1380 800 *1090 670 5.52
1 m - - - - *2740 1620 *1870 1070 *1480 770 *1140 650 5.58
0 m - - *1510 *1510 *3020 1540 *2030 1020 *1530 750 *1270 660 5.43
-1 m *2060 *2060 *2880 *2880 *2890 1520 *1980 1000 *1380 740 *1350 730 5.05
-2 m *3400 *3400 *3700 3010 *2370 1530 *1590 1020 - - *1300 910 4.35
-3 m - - *1690 *1690 *1040 *1040 - - - - *970 *970 3.07
Boom: 3.0 m
Dipper arm: 1.9 m
Shoe: 400 mm (Rubber
pad)
Counterweight: 440 kg
Dozer blade: Up
5 m - - - - - - - - - - *1380 1240 3.71
4 m - - - - - - *1280 1120 - - *1160 850 4.68
3 m - - - - - - *1360 1100 1060 760 980 690 5.24
2 m - - - - *2070 1630 1470 1050 1040 740 890 620 5.52
1 m - - - - 2170 1490 1410 990 1010 710 860 600 5.58
0 m - - *1510 *1510 2090 1410 1360 940 990 690 880 610 5.43
-1 m *2060 *2060 *2880 2670 2060 1390 1340 930 990 690 970 680 5.05
-2 m *3400 *3400 *3700 2720 2080 1410 1360 940 - - 1210 840 4.35
-3 m - - *1690 *1690 *1040 *1040 - - - - *970 *970 3.07
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
2. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
3. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
Specifications
