Volvo EC60E - Page 331

For North America
H
3.3 ft 6.6 ft 9.9 ft 13.2 ft 16.5 ft Max. Reach
Max.
Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib ft
Boom: 3.0 m (9' 10")
Dipper arm: 1.6 m (5' 3")
Shoe: 400 mm (16")
(Rubber track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Down
13.2 ft - - - - - - *3210 2510 - - *3140 2220 14.13
9.9 ft - - - - - - *3310 2480 - - *2920 1770 16.14
6.6 ft - - - - *5070 3670 *3790 2380 *3230 1680 *2920 1570 17.16
3.3 ft - - - - *6360 3390 *4300 2260 *3370 1630 *3090 1510 17.39
0 ft - - *3060 *3060 *6670 3270 *4520 2180 *3330 1600 *3200 1550 16.86
-3.3 ft *5390 *5390 *7200 6340 *6120 3250 *4220 2160 - - *3180 1750 15.49
-6.6 ft - - *6860 6470 *4650 3310 - - - - *2960 2280 12.94
Boom: 3.0 m (9' 10")
Dipper arm: 1.6 m (5' 3")
Shoe: 400 mm (16")
(Rubber track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Up
13.2 ft - - - - - - *3210 2340 - - 2860 2070 14.13
9.9 ft - - - - - - 3190 2310 - - 2290 1640 16.14
6.6 ft - - - - 4830 3390 3080 2210 2190 1560 2050 1460 17.16
3.3 ft - - - - 4540 3130 2960 2090 2140 1510 1980 1400 17.39
0 ft - - *3060 *3060 4400 3000 2880 2010 2100 1480 2040 1440 16.86
-3.3 ft *5390 *5390 *7200 5740 4380 2990 2860 1990 - - 2300 1620 15.49
-6.6 ft - - *6860 5860 4450 3050 - - - - *2960 2110 12.94
Boom: 3.0 m (9' 10")
Dipper arm: 1.6 m (5' 3")
Shoe:
380 mm (15") (Steel
track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Down
13.2 ft - - - - - - *3210 2570 - - *3140 2280 14.13
9.9 ft - - - - - - *3310 2540 - - *2920 1820 16.14
6.6 ft - - - - *5070 3760 *3790 2440 *3230 1730 *2920 1620 17.16
3.3 ft - - - - *6360 3490 *4300 2320 *3370 1680 *3090 1560 17.39
0 ft - - *3060 *3060 *6670 3360 *4520 2240 *3330 1650 *3200 1600 16.86
-3.3 ft *5390 *5390 *7200 6520 *6120 3340 *4220 2220 - - *3180 1800 15.49
-6.6 ft - - *6860 6650 *4650 3410 - - - - *2960 2350 12.94
Boom: 3.0 m (9' 10")
Dipper arm: 1.6 m (5' 3")
Shoe:
380 mm (15") (Steel
track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Up
13.2 ft - - - - - - *3210 2400 - - 2950 2120 14.13
9.9 ft - - - - - - 3280 2370 - - 2360 1690 16.14
6.6 ft - - - - 4960 3480 3180 2270 2250 1610 2120 1500 17.16
3.3 ft - - - - 4670 3210 3050 2150 2210 1560 2040 1440 17.39
0 ft - - *3060 *3060 4540 3090 2970 2070 2170 1530 2110 1480 16.86
-3.3 ft *5390 *5390 *7200 5900 4520 3070 2950 2050 - - 2370 1660 15.49
-6.6 ft - - *6860 6020 4580 3130 - - - - *2960 2170 12.94
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
2. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
3. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
330
Specifications
Lifting capacities
