Volvo EC60E - Page 332

H
3.3 ft 6.6 ft 9.9 ft 13.2 ft 16.5 ft Max. Reach
Max.
Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib ft
Boom: 3.0 m (9' 10")
Dipper arm: 1.6 m (5' 3")
Shoe:
500 mm (20") (Steel
track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Down
13.2 ft - - - - - - *3210 2620 - - *3140 2320 14.13
9.9 ft - - - - - - *3310 2590 - - *2920 1850 16.14
6.6 ft - - - - *5070 3830 *3790 2480 *3230 1760 *2920 1650 17.16
3.3 ft - - - - *6360 3550 *4300 2370 *3370 1720 *3090 1590 17.39
0 ft - - *3060 *3060 *6670 3430 *4520 2290 *3330 1680 *3200 1640 16.86
-3.3 ft *5390 *5390 *7200 6640 *6120 3410 *4220 2270 - - *3180 1840 15.49
-6.6 ft - - *6860 6770 *4650 3470 - - - - *2960 2390 12.94
Boom: 3.0 m (9' 10")
Dipper arm: 1.6 m (5' 3")
Shoe:
500 mm (20") (Steel
track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Up
13.2 ft - - - - - - *3210 2440 - - 3000 2160 14.13
9.9 ft - - - - - - *3310 2410 - - 2410 1720 16.14
6.6 ft - - - - 5060 3540 3240 2310 2300 1640 2160 1530 17.16
3.3 ft - - - - 4770 3280 3120 2190 2250 1590 2090 1470 17.39
0 ft - - *3060 *3060 4630 3150 3030 2120 2220 1560 2150 1510 16.86
-3.3 ft *5390 *5390 *7200 6010 4610 3130 3010 2090 - - 2420 1700 15.49
-6.6 ft - - *6860 6130 *4650 3200 - - - - *2960 2210 12.94
Boom: 3.0 m (9' 10")
Dipper arm: 1.6 m (5' 3")
Shoe: 400 mm (16")
(Rubber pad)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Down
13.2 ft - - - - - - *3210 2600 - - *3140 2310 14.13
9.9 ft - - - - - - *3310 2570 - - *2920 1840 16.14
6.6 ft - - - - *5070 3800 *3790 2470 *3230 1750 *2920 1640 17.16
3.3 ft - - - - *6360 3530 *4300 2350 *3370 1700 *3090 1580 17.39
0 ft - - *3060 *3060 *6670 3400 *4520 2270 *3330 1670 *3200 1620 16.86
-3.3 ft *5390 *5390 *7200 6590 *6120 3380 *4220 2250 - - *3180 1820 15.49
-6.6 ft - - *6860 6720 *4650 3450 - - - - *2960 2370 12.94
Boom: 3.0 m (9' 10")
Dipper arm: 1.6 m (5' 3")
Shoe: 400 mm (16")
(Rubber pad)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Up
13.2 ft - - - - - - *3210 2420 - - 2980 2150 14.13
9.9 ft - - - - - - *3310 2390 - - 2390 1710 16.14
6.6 ft - - - - 5020 3520 3220 2290 2280 1630 2140 1520 17.16
3.3 ft - - - - 4730 3250 3090 2180 2240 1580 2070 1460 17.39
0 ft - - *3060 *3060 4590 3130 3010 2100 2200 1550 2140 1500 16.86
-3.3 ft *5390 *5390 *7200 5970 4580 3110 2990 2080 - - 2400 1690 15.49
-6.6 ft - - *6860 6090 4640 3170 - - - - *2960 2200 12.94
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
2. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
3. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
Specifications
Lifting capacities 331
