Volvo EC60E - Page 333

H
3.3 ft 6.6 ft 9.9 ft 13.2 ft 16.5 ft Max. Reach
Max.
Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib ft
Boom: 3.0 m (9' 10")
Dipper arm: 1.9 m (6' 3")
Shoe: 400 mm (16")
(Rubber track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Down
16.5 ft - - - - - - - - - - *3060 2890 12.05
13.2 ft - - - - - - *2830 2540 - - *2560 1950 15.32
9.9 ft - - - - - - *3000 2490 *2900 1720 *2400 1590 17.17
6.6 ft - - - - *4530 3720 *3510 2380 *3040 1680 *2400 1430 18.11
3.3 ft - - - - *5990 3410 *4100 2250 *3260 1620 *2520 1370 18.33
0 ft - - *3370 *3370 *6610 3230 *4440 2150 *3340 1570 *2800 1410 17.83
-3.3 ft *4560 *4560 *6410 6200 *6320 3190 *4330 2110 *3000 1560 *2970 1550 16.56
-6.6 ft *7540 *7540 *8080 6320 *5170 3230 *3450 2140 - - *2860 1940 14.25
-9.9 ft - - *3610 *3610 *2160 *2160 - - - - *2110 *2110 9.98
Boom: 3.0 m (9' 10")
Dipper arm: 1.9 m (6' 3")
Shoe: 400 mm (16")
(Rubber track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Up
16.5 ft - - - - - - - - - - *3060 2690 12.05
13.2 ft - - - - - - *2830 2370 - - 2520 1810 15.32
9.9 ft - - - - - - *3000 2320 2220 1590 2070 1480 17.17
6.6 ft - - - - *4530 3440 3090 2210 2180 1550 1870 1320 18.11
3.3 ft - - - - 4560 3140 2960 2080 2120 1500 1810 1270 18.33
0 ft - - *3370 *3370 4370 2970 2850 1980 2070 1450 1860 1300 17.83
-3.3 ft *4560 *4560 *6410 5600 4310 2920 2810 1940 2060 1440 2050 1430 16.56
-6.6 ft *7540 *7540 *8080 5710 4360 2960 2840 1970 - - 2560 1790 14.25
-9.9 ft - - *3610 *3610 *2160 *2160 - - - - *2110 *2110 9.98
Boom: 3.0 m (9' 10")
Dipper arm: 1.9 m (6' 3")
Shoe:
380 mm (15") (Steel
track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Down
16.5 ft - - - - - - - - - - *3060 2960 12.05
13.2 ft - - - - - - *2830 2600 - - *2560 2000 15.32
9.9 ft - - - - - - *3000 2560 *2900 1760 *2400 1640 17.17
6.6 ft - - - - *4530 3810 *3510 2440 *3040 1720 *2400 1470 18.11
3.3 ft - - - - *5990 3500 *4100 2310 *3260 1660 *2520 1410 18.33
0 ft - - *3370 *3370 *6610 3320 *4440 2210 *3340 1620 *2800 1450 17.83
-3.3 ft *4560 *4560 *6410 6360 *6320 3270 *4330 2170 *3000 1610 *2970 1600 16.56
-6.6 ft *7540 *7540 *8080 6480 *5170 3310 *3450 2200 - - *2860 2000 14.25
-9.9 ft - - *3610 *3610 *2160 *2160 - - - - *2110 *2110 9.98
Boom: 3.0 m (9' 10")
Dipper arm: 1.9 m (6' 3")
Shoe:
380 mm (15") (Steel
track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Up
16.5 ft - - - - - - - - - - *3060 2760 12.05
13.2 ft - - - - - - *2830 2430 - - *2560 1860 15.32
9.9 ft - - - - - - *3000 2380 2290 1640 2140 1520 17.17
6.6 ft - - - - *4530 3530 3180 2270 2250 1600 1930 1360 18.11
3.3 ft - - - - 4690 3230 3050 2140 2190 1540 1870 1310 18.33
0 ft - - *3370 *3370 4500 3050 2940 2040 2140 1490 1920 1340 17.83
-3.3 ft *4560 *4560 *6410 5760 4450 3010 2900 2000 2130 1490 2120 1480 16.56
-6.6 ft *7540 *7540 *8080 5870 4490 3050 2930 2030 - - 2650 1850 14.25
-9.9 ft - - *3610 *3610 *2160 *2160 - - - - *2110 *2110 9.98
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
2. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
3. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
332
Specifications
Lifting capacities
