Volvo EC60E - Page 334

H
3.3 ft 6.6 ft 9.9 ft 13.2 ft 16.5 ft Max. Reach
Max.
Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib Ib ft
Boom: 3.0 m (9' 10")
Dipper arm: 1.9 m (6' 3")
Shoe:
500 mm (20") (Steel
track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Down
16.5 ft - - - - - - - - - - *3060 3010 12.05
13.2 ft - - - - - - *2830 2650 - - *2560 2040 15.32
9.9 ft - - - - - - *3000 2600 *2900 1800 *2400 1670 17.17
6.6 ft - - - - *4530 3880 *3510 2490 *3040 1760 *2400 1500 18.11
3.3 ft - - - - *5990 3570 *4100 2360 *3260 1700 *2520 1450 18.33
0 ft - - *3370 *3370 *6610 3390 *4440 2260 *3340 1650 *2800 1480 17.83
-3.3 ft *4560 *4560 *6410 *6410 *6320 3350 *4330 2220 *3000 1640 *2970 1640 16.56
-6.6 ft *7540 *7540 *8080 6620 *5170 3390 *3450 2250 - - *2860 2040 14.25
-9.9 ft - - *3610 *3610 *2160 *2160 - - - - *2110 *2110 9.98
Boom: 3.0 m (9' 10")
Dipper arm: 1.9 m (6' 3")
Shoe:
500 mm (20") (Steel
track)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Up
16.5 ft - - - - - - - - - - *3060 2800 12.05
13.2 ft - - - - - - *2830 2470 - - *2560 1900 15.32
9.9 ft - - - - - - *3000 2420 2340 1670 2180 1550 17.17
6.6 ft - - - - *4530 3590 3250 2310 2300 1630 1980 1390 18.11
3.3 ft - - - - 4790 3290 3110 2180 2240 1570 1910 1340 18.33
0 ft - - *3370 *3370 4600 3120 3010 2090 2190 1530 1960 1370 17.83
-3.3 ft *4560 *4560 *6410 5870 4550 3070 2960 2050 2180 1520 2170 1510 16.56
-6.6 ft *7540 *7540 *8080 5980 4590 3110 2990 2080 - - 2700 1880 14.25
-9.9 ft - - *3610 *3610 *2160 *2160 - - - - *2110 *2110 9.98
Boom: 3.0 m (9' 10")
Dipper arm: 1.9 m (6' 3")
Shoe: 400 mm (16")
(Rubber pad)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Down
16.5 ft - - - - - - - - - - *3060 2990 12.05
13.2 ft - - - - - - *2830 2630 - - *2560 2030 15.32
9.9 ft - - - - - - *3000 2590 *2900 1790 *2400 1660 17.17
6.6 ft - - - - *4530 3850 *3510 2470 *3040 1750 *2400 1490 18.11
3.3 ft - - - - *5990 3540 *4100 2340 *3260 1690 *2520 1430 18.33
0 ft - - *3370 *3370 *6610 3370 *4440 2240 *3340 1640 *2800 1470 17.83
-3.3 ft *4560 *4560 *6410 *6410 *6320 3320 *4330 2200 *3000 1630 *2970 1620 16.56
-6.6 ft *7540 *7540 *8080 6570 *5170 3360 *3450 2230 - - *2860 2020 14.25
-9.9 ft - - *3610 *3610 *2160 *2160 - - - - *2110 *2110 9.98
Boom: 3.0 m (9' 10")
Dipper arm: 1.9 m (6' 3")
Shoe: 400 mm (16")
(Rubber pad)
Counterweight: 440 kg
(970 Ib)
Dozer blade: Up
16.5 ft - - - - - - - - - - *3060 2790 12.05
13.2 ft - - - - - - *2830 2450 - - *2560 1880 15.32
9.9 ft - - - - - - *3000 2410 2320 1660 2170 1540 17.17
6.6 ft - - - - *4530 3570 3220 2300 2280 1620 1960 1380 18.11
3.3 ft - - - - 4750 3270 3090 2170 2220 1560 1890 1330 18.33
0 ft - - *3370 *3370 4560 3090 2980 2070 2170 1510 1940 1360 17.83
-3.3 ft *4560 *4560 *6410 5830 4510 3050 2940 2030 2160 1510 2150 1500 16.56
-6.6 ft *7540 *7540 *8080 5940 4550 3090 2970 2060 - - 2680 1870 14.25
-9.9 ft - - *3610 *3610 *2160 *2160 - - - - *2110 *2110 9.98
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
2. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
3. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
Specifications
Lifting capacities 333
