VA41620/VA41630 Evaluation Board User’s Manual
V1.0
18
Command
Arguments
Comments
$help
none
Provides list of all available commands
$help
$readport [port 0-6] [mask] Masked pins input, read IO port
$setport [port 0-6] [mask] [val] - Set masked pins hi/loon Port output 1 or 0
$readadc [ch 0-15] - Readan ADC channel
$setdac [0 or 1] [0x0 0xfff] Set DAC0 or DAC1 output
$romlwr [addr] [data32] Write word to SPI boot FRAM
$romlrd [addr] Read word from SPI boot FRAM
$auxwr [addr] [data32] - Write word to aux FRAM
$auxrd [addr] Read word from aux FRAM
$ebiinitInitialize external mem interface
$ebiwrite [addr] [data32] Write word to EBI
$ebiread [addr]Red word from EBI
$cantestCAN bus loopback test
$ethtestEthernet test
$spwtestSpaceWire test
$i2ctestI2C test I2C1(m) -. I2C2(s)
$accel [(opt) 1: enable every sec] Get accelerometer data
$brdtmp [(opt) 1: en every sec]Get board temperature
$rstsRead reset source register
$fwverGet firmware version
$srstSoftware reset
$helpPrint help
Note:
$i2ctest - Requires I2CA and I2CB be externally connected together
$cantest Requires CAN0 and CAN1 be externally connected together
$readport
[portNum] [mask]
Ports A through port G are read and a 16-bit hex value is displayed for ports A-F and 8-bit hex
value is read for port G. Ports A through G are accessed with portNum 0 through 6.
Example: $readport 0 0x00ff
Response: OK 0x1234
Note: Some GPIO are dedicated to certain peripherals by the software included with this
package.
PORTA [7:4]: SPI2
PORTB [15:12]: UART1
PORTF [5:2]: SPI1
PORTF [9:6]: UART2
PORTG [1:0]: UART0
PORTG [4]: SPI1 (FRAM chip select)
$setport
[portNum] [mask]
[val]
Sets a single port to a value depending on the mask
Example: $setport 0 0x00ff 0x0055
Response: “OK if port number is valid, “ERR is reported for invalid port number.
$readadc
[channelNum]
Reads the value of the specified ADC channel
Example: $readadc 11
Response: $OK 0x0373
$setdac
[dacNum] [data]
Sets the output of DAC0 or DAC1 to the voltage corresponding to the data [hex value 0x0 to
0xfff]
Example: $setdac 0 0x800
Response: $OK
ANOUT0 will be set to ½ VDDREF, or about 1.65v
$rom1wr
[addr] [data32]
Writes one address location of the SPI boot FRAM device.
Example: $rom1wr 0x0 0x0
