47
WWW.VORONDESIGN.COM
APPLY LUBRICATION
A thin layer of lubrication will
prevent rust.
IMPROVISED STOPS
Push the brackets onto the rods, they
will prevent the rods from slipping
out.
Z AXIS RODS
8mm Shaft
