SOLDER WIRES
Solder 500mm of wire to the microswitch
before inserting it ush into the housing.
PRELOADED NUTS
The nuts have been installed several chapters before.
Y ENDSTOP
Microswitch
M3x16 SHCS
M5x16 BHCS
