9
V1.0.0
Z Drive
GT2 20T Pulley (6mm Wide)
Use Provided Tool To De-flange
M3x8 BHCS
Ensure Tooth Alignment During Press-Fit
Do Not Discard, See Appendix A For Pulley Modification
