WWW.VORONDESIGN.COM
CAD version: ERCF V2
107107
LINEAR AXIS
M3x8 SHCS
NEMA 17 Pancake Motor
MOTOR WIRES
Make sure the wires of the motor
are coming out from this side.
SELECTOR MOTOR SUPPORT
[a]_Motor_Lock †
