VORON ERCF v2 - Arm Groups and Coupler Block Assembly

WWW.VORONDESIGN.COM
Enraged Rabbit Cotton Tail
4x M3x8mm SCHS
1x 608ZZ Bearing
1x M3x5x4 Heat Insert
1x M3 Roll-in T-Nut
1x M3x16mm SCHS
ARM GROUPS
B
A
C
EXPLODED VIEW
A
B
C
D
E
ARM GROUP BOM
(PER CHANNEL)
D
A
F
G
H
I
J
1x [a]_Support_Arm_Mount_xN.stl
2x Tag_Plates
1x [a]_Support_Arm_xN.stl
1x Buffer_Wheel_xN.stl
1x Axle_Spacer_Standard_xN.stl
F
H
I
G
G
ARM GROUP PRINTED PARTS
(PER CHANNEL)
J
E
