CAD version: ERCF V2
FILAMENT BLOCKS
AC
D
B
E
G
1x 3mm x 20mm pin
2x 6x3x2mm Magnets
1x BMG Idler Gear & Bearings
1x ECAS-M4 Adapter
1x M3 Set Screw
1x M3x8mm SHCS
1x M3x16mm SHCS
1x MR85ZZ Bearing
A
B
C
D
E
F
G
H
FILAMENT BLOCK SUB-BOM
(PER FILAMENT BLOCK)
5454
M
K
I
N
J
L/O
H
I
J
K
L
M
N
1x [a]_Base_Trap_M3_xN.stl
1x [a]_Tophat_xN.stl
1x [a]_Latch_xN.stl
2x [a]_Tag_plates_N_x2.stl
1x Base_xN.stl
1x Filament_Path_xN.stl
2x Tag_plates_DigitN_x2.stl
I
J
K
L
M
N
O
H
F
EXPLODED VIEW
