WWW.VORONDESIGN.COM
CAD version: ERCF V2
FILAMENT END BLOCK
Insert 4 M3 T Nuts into the side channels of the 2020
extrusion as shown.
7474
END BLOCK
M3 T Nuts
FILAMENT END BLOCK
