WWW.VORONDESIGN.COM
CAD version: ERCF V2
7777
END BLOCK
M5x30 SHCS
M5 Nut
FILAMENT BLOCK END FOOT
WHAT ABOUT THE M5x30 SCREW AND M5 NUT?
We’ll use these later in the Final Assembly steps.
