WWW.VORONDESIGN.COM
CAD version: ERCF V2
8888
SELECTOR
SERVO MOUNT PRINT IN PLACE SUPPORTS
Use a small tool, like a small flat screwdriver to
remove the built-in supports.
The Towerpro MG90S version has 4 supports. If
the inner supports don’t break out cleanly, you
may need to clean up the slot with a file or hobby
knife to get a good fit.
Servo_Mount_MG90S Servo_Mount_Savox
Remove
Remove Remove
SERVO MOUNT PREPARATION
