CAD version: ERCF V2
9090
SELECTOR
SPRING CAP
Twist the spring onto the
Selector_Spring_Cap so the cap stays
inserted into the spring.
Insert the spring and cap into the hole
in the selector and make sure its not
obstructed.
Shorter 10mm springs can be
used as well.
Selector_Spring_Cap
12x6mm 1mm OD
Compression Spring
SPRING INSTALL
