WWW.VORONDESIGN.COM
CAD version: ERCF V2
9393
SELECTOR
Zip Tie
SERVO WIRES
Secure the servo wires using a zip tie. Make sure the
wires lie flat against the side of the servo as shown.
SERVO WIRES
