FAN ASSEMBLY
DON’T OVER TIGHTEN
The screws are screwed
directly into plastic.
REMOVE TOP COVER
Split the fan open by
bending the tabs on the
side.
M3x16 SHCS
WIRING PATH
Route the wires through the large opening in the back.
