91
WWW.VORONDESIGN.COM
FAN ASSEMBLY
Piece of Filament
AIRFLOW DIRECTION
Make sure the fan blows air towards
the hotend.
Look for a small arrow on the fan
housing.
WIRING PATH
Guide the wires in the
highlighted path.
