9 8
RANGER
®
13 0 0
LASER RANGEFINDER
3. Choose the Brightness Setting. The Ranger
®
1300
provides three illumination settings. Press the Measure
button to toggle through the three Brightness settings.
Press the Menu button to save your desired setting and
move back to HCD/LOS selection screen.
To exit Mode Selection and save settings, press and hold
the Menu button for four seconds. Settings will also save
when Ranger
®
1300 powers down automatically.
Ranging
With the Ranger
®
1300 powered up, position the crosshair
on the target object and press and release the Measure button
to get the distance measurement. If the laser is not able
to range due to the reflectivity of the target, you will see a
display similar to that shown here. To range a new target,
simply re-aim and press the Measure button again.
No Range Returned HCD Scan LOS Scan
Scan Ranging
With the Ranger
®
1300 powered up, activate Scan Ranging
by pressing and holding the Measure button down. A blinking
“S” will appear in the lower left corner.
Keeping the button depressed will continuously measure
distance as you pan the crosshair back and forth across target
objects. Releasing the Measure button will return laser to the
Power Up Condition.
Choose Between One of Three Brightness Settings
