Vox Valveronix ToneLab LE User Manual

Part Number
Category
Part Name
Note
Reference QTY
510450525014
LED Spacer
LH5-7 (L=7MM) LH5-070
KLM-2753/2754/2755/2756
21
510450525013
LED Spacer
PTLMA120BKV0 (LMA-120)
KLM-2753/2754/2755/2756
7
510C51522753
PCB ASS'Y
KLM-2753/2754/2755/2756 ASS'Y
KLM-2753/2754/2755/2756
1
510312510501
LED
12-21UYC /S400/ TR8 (S)
LCD
LED1 LED2
2
510335510003
CRYSTAL
HC-49US 10.000MHZ SMD (S)
LCD
X1
1
510320512001
RESET IC
M51957AFP-CF1J TS (S)
LCD
IC3
1
500324043002
IC
CAT24C128WI-GT3
LCD
IC2
1
500320004728
CPU
HD64338347A12HV(X5560-3)
LCD
IC1
1
510474510005
CONNECTOR
200135FA036S200ZU (36PIN HEAD)
LCD
CN1
1
510C51522757
PCB ASS'Y
KLM-2757 ASS'Y
1/4
510405500010
LCD
DLC-90106G4GT
LCD1
1
510465500001
VACUUM TUBE
12AX7EH
1
510405540017
AC ADAPTER
KA-161EV
100V
(1)
510405540018
AC ADAPTER
KA-163EV
120V
(1)
510405540019
AC ADAPTER
KA-165EV
240V
(1)
510405540020
AC ADAPTER
KA-169EV
230V
(1)
500540023500
PLUG
ECP01 05A
for UK
(1)
510640505002
MECHANICAL
X-2700 SIDEBOARD (L) C30595-1
AL(AH100), T=5.0
1
510640505003
MECHANICAL
X-2700 SIDEBOARD(R) C30595-2
AL(AH100), T=5.0
1
510640503501
MECHANICAL
X-2700 PEDAL KOC-C20389-1
AL(ADC12),NI-CR PLATING
1
510640505514
MECHANICAL
X-2700 PEDAL SUPPORT C41281
SECC, t=1.6
1
510646502014
MECHANICAL
X-2700 PEDAL SHAFT KOC-C41289
φ
6, CR PLATING
1
510640505511
MECHANICAL
X-2700 GLIP PLATE KOC-C41326
SECC, t=1.2
1
510640505531
MECHANICAL
X-3570 ENCODER ANGLE C41393
SECC, t=1.0
2
510374522501
PUSH SW
FC7108 F/PEDAL (W/ N&W) (D)
SWITCH ACTUATOR
7
500646077600
MECHANICAL
X-0400 BL PLATE KOC-E40525
PC, TRANSPARENCE
1
500620018201
MECHANICAL
PSW KNOB (EXPORT) E40224
ABS-HB, BLACK
1
510646500501
MECHANICAL
X-2700 SHAFT GRIP KOC-E40558
POM
1
510500500006
MECHANICAL
X-2700 PEDAL RUBBER KOC-E30310
SYNTHETIC RUBBER
1
510646502053
MECHANICAL
X-3570 VR KNOB KOC-E40632-1
ABS-HB
1
510685501511
MECHANICAL
X-0400 REFLECTION SHEET F40971
PE
1
510800500005
MECHANICAL
X-0400 SHEET KOC-F40972
TRACING PAPER
1
510500502506
INTER CONNECTOR
INTER-CONNECTOR YP L58XW2XH6.0
2
510500500008
MECHANICAL
X-332CHINA URETHANE-LEG F40709
PORON HH48-C
6
510646504519
MECHANICAL
X-2550 LED GUIDE KOC-F41097
PP, t=0.8
1
510500502003
MECHANICAL
X-951G SWITCH CUSHION F40906
NEOPRENE RUBBER
1
510500501512
MECHANICAL
X-5560 PEDAL CUSHION F3 F41309
PORON FH-48
1
510500500507
MECHANICAL
X-2550 PEDAL CUSHION R3 F41114
PORON HH-48,FH-48
2
510646506011
MECHANICAL
X-3570 REFLECTION SHEET F41178
PAPER
1
510640505546
MECHANICAL
X-5560 UPPER CASE C20440
SECC-GX-KS, t=1.2, Paint,Print
1
510640505547
MECHANICAL
X-5560 BOTTOM CASE C20441
SECC-GX-KS, t=1.0
1
510640505548
MECHANICAL
X-5560 PEDAL ANGLE C41473
SECC,t=1.6mm.Cleaning
1
510640505549
MECHANICAL
X-5560 SUPPORT ANGLE C41469
SECC-GX-KS, t=1.0
1
510640505550
MECHANICAL
X-5560 SWITCH ANGLE(2) C41470
SECC,t=1.0mm.Cleaning
2
510640505551
MECHANICAL
X-5560 SWITCH ANGLE(3) C41471
SECC,t=1.0mm.Cleaning
1
510640505552
MECHANICAL
X-5560 TUBE ANGLE C41472
SECC,t=1.6mm.Cleaning
1
510646504166
MECHANICAL
X-5560 LCD FRAME E30439
ABS-HB,Black
1
510646504167
MECHANICAL
X-5560 4SERIAL BUTTON E20280
ABS-HB,Semi-transparent
2
510646504060
MECHANICAL
X-2540 KNOB KOC-E40572
ABS-HB
2
510646502054
MECHANICAL
X-3570 KNOB KOC-E40572-2
ABS-HB PAINTING
3
510646504170
MECHANICAL
5560KNOB(L) E40685
ABS-HB,Plating
6
510646506509
MECHANICAL
X-5560 LCD WINDOW E40686
PC,t=1.0mm,Silk Printing
1
510500501513
MECHANICAL
X-5560 TUBE CUSHION F41304
PE FOAM
1
510500501514
MECHANICAL
X-5560 PCB CUSHION F41305
PORON
1
510646506012
MECHANICAL
X-3570 PCB CUSHION KOC-F41215
RUBBER SPONGE
1
510630500003
MECHANICAL
X-5560 SHIELD SHEET KOC-F30129
ALPET + PET
1
