Vox Valveronix ToneLab LE User Manual

VOX ToneLab LE Part List
Part Number
Category
Part Name
Note
Reference QTY
510402511508
EMI/EMC PART
BLM18AG102SN1 (1608) (S)
KLM-2751/2752/2758
L1-L11,L14,L17,L18,L20,L21
18
,L305,L306,L310
510450527001
CONNECTOR
BA-20SG (20PIN SOCKET) (D)
KLM-2751/2752/2758
CN3
1
510474520012
CONNECTOR
JS-1132-03 (B3B-EH-A) (WAF)(D)
KLM-2751/2752/2758
CN2
1
510474520019
CONNECTOR
JS-1125-07 (WAF FOR VOLUME)(D)
KLM-2751/2752/2758
CN303
1
510640505543
X-3570 DIN JACK CASE C41445
KLM-2751/2752/2758
1
510450520016
DIN PLUG/JACK
DIN-520BX2 (D)
KLM-2751/2752/2758
MIDI1
1
510450524501
PHONE JACK
LJB0661-6 (PHONE JACK) (D)
KLM-2751/2752/2758
PH1,PH2,PH3,PH4,PH5
5
510640502508
X-2540 GND PLATE KOC-C41304
KLM-2751/2752/2758
GC1-GC5
5
510450520503
PHONE JACK
EJS-3-1635-01 (STEREO MINI)(D)
KLM-2751/2752/2758
PH7
1
500330003600
OPTO TX/RX MODULE
TOTX179L
KLM-2751/2752/2758
OPT1
1
510309520001
OPTICAL SENSOR
RPR-359F(RANK C OR D)(D)
KLM-2751/2752/2758
PR1
1
510310511502
DIODE
1SS355 TE17 (S)
KLM-2751/2752/2758
D1,D3,D4
3
510310511503
DOUBLE DIODES
DA204U T106
KLM-2751/2752/2758
WD1,WD2,WD3,W D4,WD5
5
500330003700
PHOTO COUPLER
PS9117-F3-A
KLM-2751/2752/2758
PC1
1
510335520008
CRYSTAL
HC-49US 22.5792MHZ (D)
KLM-2751/2752/2758
X1
1
510300510503
TRANSISTOR
2SA812-T1B M5-7 M6 RANK (S)
KLM-2751/2752/2758
Q10
1
510300520506
TRANSISTOR
2SC4213-A (TE85L,F)(S)
KLM-2751/2752/2758
Q1,Q2,Q3,Q4,Q5
5
510300511005
DIGITAL TR
DTC114EUA T106 (S)
KLM-2751/2752/2758
Q6,Q7
2
510300510502
TRANSISTOR
2SC1623A-T1B AT
KLM-2751/2752/2758
Q8,Q9
2
510320514018
REGULATOR IC
BA3257FP
KLM-2751/2752/2758
IC17
1
510320512501
OPAMP
UPC4570G2-E2 TS
KLM-2751/2752/2758
IC7,IC9,IC11,IC15,IC18,IC21,IC301
7
510320520502
OPAMP
NJM4556AD (D)
KLM-2751/2752/2758
IC3
1
510320514011
OPAMP
BA10358F-E2 (S)
KLM-2751/2752/2758
IC20
1
510320511003
OPAMP
NJM4580M-TE1-#ZZZB (S)
KLM-2751/2752/2758
IC5
1
500324041005
SRAM
EM643FV16FU-70LF
KLM-2751/2752/2758
IC13,IC22
2
500320012334
IC
MB87R1420PMC-G-BND
KLM-2751/2752/2758
IC14
1
510320519513
A/D Converter
AK5381VT
KLM-2751/2752/2758
IC16,IC302
2
510324038010
D/A Converter
AK4384ET-E2
KLM-2751/2752/2758
2
510320510504
Logic IC
HD74HC05FPEL-E-Q
KLM-2751/2752/2758
IC2
1
510320517004
Logic IC
TC7WU04F (SM8) / (FM8) (S)
KLM-2751/2752/2758
IC12,IC24
2
510320516001
Logic IC
SN74LV245APWR (S)
KLM-2751/2752/2758
IC6
1
510320516036
Logic IC
SN74HCT125DR
KLM-2751/2752/2758
IC1
1
510320516037
Logic IC
CD4066BNSR
KLM-2751/2752/2758
IC4
1
510360520009
ROTARY VR
RK09L12B0A4S (10KAX2/15MM) (D)
KLM-2751/2752/2758
VR2
1
510374520008
TRIMER VR
RH0614CN4J (33K) (D)
KLM-2751/2752/2758
VR1
1
510470521549
HARNESS
HNS-3547 (3P HARNESS60 BD-IN)
KLM-2751/2752/2758
CN1
1
510470521065
Board-in Harness
HNS-3773 Jack-REG
KLM-2751/2752/2758
CN4-CN5
1
510460501001
FUSE
0218 02.5M XP(TIME LAG 250V T2.5AL)
KLM-2751/2752/2758
F1
1
510460500001
FUSE HOLDER
CNT47-0003A (FUSE HOLDER) (TR)
KLM-2751/2752/2758
FU1
2
510C51522751
PCB ASS'Y
KLM-2751/2752/2758 ASS'Y
KLM-2751/2752/2758
1
510312513003
Chip LED
TO2013BC-MYE (S) (YELLOW)
KLM-2751/2752/2758
LED1
1
510374520009
TRIMER VR
RH0614CJ3J (2.2K) (D)
KLM-2751/2752/2758
VR301
1
510402520001
INDUCTOR
TC-221M-1A-5026-SN (D)
KLM-2751/2752/2758
L301
1
510402512502
OUTPUT TRANS
LCL-1653WH
KLM-2751/2752/2758
T301
1
510402512503
AF COIL
CH0912-154K(148mH)
KLM-2751/2752/2758
L302
1
510300511014
DIGITAL TR
DTC144EUA T106 (S)
KLM-2751/2752/2758
DT305,DT306,DT307,DT308
4
510300511019
DIGITAL TR
DTC115EUA (S)
KLM-2751/2752/2758
DT301,DT304
2
510300511020
DIGITAL TR
DTA144EUA (S)
KLM-2751/2752/2758
DT302,DT303
2
510402520502
LCR EMI FILTER
DST9ND31H223Q92A (TR) (S)
KLM-2751/2752/2758
L307,L309
2
510300520505
TRANSISTOR
2SC4117 (BL RANK)
KLM-2751/2752/2758
Q302,Q303
2
510320511020
OPAMP
NJM2082M
KLM-2751/2752/2758
IC304,IC305
2
510320521002
ANALOG IC
MAX361ESE (16NARROW) (S)
KLM-2751/2752/2758
IC306
1
510320511028
IC regulator
NJM78M15DL1A
KLM-2751/2752/2758
IC308
1
510320511029
IC regulator
NJM79M15DL1A
KLM-2751/2752/2758
IC309
1
510320521503
REGULATOR IC
NJM7906FA-#ZZZB (D)
KLM-2751/2752/2758
IC310
1
510320522501
REGULATOR IC
PQ1CG1J0000H (D)
KLM-2751/2752/2758
IC307
1
510310511501
DIODE
1SR154-400 TE25 (PMDS) (S)
KLM-2751/2752/2758
D301,D302,D303,D304,D307,
9
D308,D309,D310,D311
510310511506
SCHOTTKY DIODE
RB051L-40TE25 (S)
KLM-2751/2752/2758
D306
1
510374520007
POWER SW
PSW SDKLA10200 (D)
KLM-2751/2752/2758
SW1
1
510450525501
DIN JACK
DJ-004-C (DIN 4P POWER) (D)
KLM-2751/2752/2758
DIN1
1
510470521050
HARNESS
HNS-3631 (X-4130)
KLM-2753/2754/2755/2756
CN12-CN22,CN11-CN21
2
510470521066
Board-in Harness
HNS-3774
KLM-2753/2754/2755/2756
CN13
1
510470521067
Board-in Harness
HNS-3775
KLM-2753/2754/2755/2756
CN302
1
510470521068
Board-in Harness
HNS-3776
KLM-2753/2754/2755/2756
CN2
1
510474510006
CONNECTOR
200112MS036S200ZU (36PIN HEAD)
KLM-2753/2754/2755/2756
CN1
1
510474520078
CONNECTOR
A2001WR-5P
KLM-2753/2754/2755/2756
CN23
1
510450526501
TUBE SOCKET
G2C9-Y 9P (TUBE SOCKET) (D)
KLM-2753/2754/2755/2756
Q301
1
510374522010
TACT SW
TC-0408T-A00 (D)
KLM-2753/2754/2755/2756
SW301-304,SW401-404,
17
SW501-504,SW601-604,SW902
510374522009
TACT SW
TC-0102T-A00 (4.3MM) (D)
KLM-2753/2754/2755/2756
SW704
1
510374520005
TACT SW
SKHCABA010 (D)
KLM-2753/2754/2755/2756
SW701-703 SW801-804
7
510310520501
DIODE
1SS133 T-77 (D)
KLM-2753/2754/2755/2756
D101-104,D201-204,D301-304,
33
D401-404,D501-504,D601-604
,D701-704,D801-804,D902
510312521502
LED
MSB31DA-1 (W/PLATING) (D)
KLM-2753/2754/2755/2756
LED501-508 LED601-606
21
(RED DIFFUSED 3MM)
LED701-707
510312521005
LED
L-59SRSGW-CC (D)(RED/GREEN)
KLM-2753/2754/2755/2756
LED301-308
8
510316521501
LED
TOD-5261BH-D (D)
KLM-2753/2754/2755/2756
LED101
1
510450522001
X-2700 LED SPACER(7SEG) F41043
KLM-2753/2754/2755/2756
1
510320514012
Logic IC
SN74HC595N (D)
KLM-2753/2754/2755/2756
IC1-IC2
2
510300520001
DIGITAL TR
DTA114ESA TP (D)
KLM-2753/2754/2755/2756
Q1-Q7
7
510300511021
DIGITAL TR
DTC114ESA TP (S)
KLM-2753/2754/2755/2756
Q9-Q16
8
500370005700
SW
REB161(9X7)PVB20FHGRY1-4-16PCE
KLM-2753/2754/2755/2756
S101,S201
2
510360522505
VR
R1626N1AP4B10K 11C N/STOP 15MM
KLM-2753/2754/2755/2756
VR1-VR3
3
510360522511
VR
RN1613N12A1-B10K NON-STOPPER
KLM-2753/2754/2755/2756
VR4-VR9
6
