8
MONITOR FEATURES SB10M1
1. Power Button
This button is used to turn the system ON/OFF.
2. Home Button
This button is used to display the Home Menu Screen.
3. IR Transmitter
Used to broadcast the audio signal to the wireless headphones.
4. Reset
This button provides a system-level power reset. It does not aect
the user settings.
5. Micro SD Card Slot
This input supports media playback from micro SD cards (up to
64GB).
6. Wired Headphone Jack
For use with wired headphones equipped with a 3.5mm cable.
7. USB Port
This input supports media playback from a USB thumb drive (up to
64GB). This port will also support USB charging (1amp) to provide
power to a device that requires external USB power.
8. HDMI Input
This input is used to connect a HDMI compatible device.
