m) r.m.s., before modulation is applied.
n) The ISM (industrial, scientific and medical) bands between 0,15 MHz and 80 MHz are 6,765 MHz
to 6,795 MHz; 13,553 MHz to 13,567 MHz; 26,957 MHz to 27,283 MHz; and 40,66 MHz to 40,70
MHz. The amateur radio bands between 0,15 MHz and 80 MHz are 1,8 MHz to 2,0 MHz, 3,5 MHz to
4,0 MHz, 5,3 MHz to 5,4 MHz, 7 MHz to 7,3 MHz, 10,1 MHz to 10,15 MHz, 14 MHz to 14,2 MHz,
18,07 MHz to 18,17 MHz, 21,0 MHz to 21,4 MHz, 24,89 MHz to 24,99 MHz, 28,0 MHz to 29,7 MHz
and 50,0 MHz to 54,0 MHz.
o) Applicable to ME EQUIPMENT and ME SYSTEMS with RATED input current less than or equal to
16 A / phase and ME EQUIPMENT and ME SYSTEMS with RATED input current greater than 16 A /
phase.
p) Applicable to ME EQUIPMENT and ME SYSTEMS with RATED input current less than or equal to
16 A / phase.
q) At some phase angles, applying this test to ME EQUIPMENT with transformer mains power input
might cause an overcurrent protection device to open. This can occur due to magnetic flux saturation
of the transformer core after the voltage dip. If this occurs, the ME EQUIPMENT or ME SYSTEM shall
provide BASIC SAFETY during and after the test.
r) For ME EQUIPMENT and ME SYSTEMS that have multiple voltage settings or auto ranging voltage
capability, the test shall be performed at the minimum and maximum RATED input voltage. ME
EQUIPMENT and ME SYSTEMS with a RATED input voltage range of less than 25 % of the highest
RATED input voltage shall be tested at one RATED input voltage within the range. See Table 1 Note
c
for examples calculations.
