60 degrees
Shooting area
23 inches
20 inches
The diagrams below demonstrate an example of doorbell camera position to view a
visitor about 20 inches from the camera. The camera in this example is set in default
angle (0 degree).
You may move the lever at the back of the doorbell to adjust the shooting area (the
camera lens).
Locating the doorbell
To adjust the shooting area, you may either relocate the doorbell in different height
level, or adjust the camera angle (see below).
To adjust the camera angle:
Tilt the lever to adjust the angle of the camera lens. The camera lens can be
adjusted to left, right or down, up to 10 degrees.
•
