Illustration 12
Examples of the display after the first measurement cycle.
After the “mirror cleaning” cycle is completed, the analyzer carries out a self-diagnostic cycle.
Then, when this cycle is complete, the unit repeats the measurement cycle starting from the
beginning.
If the measured dew point value lies below the CP 2M’s measurement range, the following
message will be shown on the display (illus. 13):
Illustration 13
CP 2M display for a dpW outside the analyzer’s measurement range.
In the hydrocarbon measurement mode (dpHC), if water condenses before hydrocarbon
condensation can be registered, the analyzer’s display shows the following message:
Illustration 14
CP 2M display for dpHC outside the analyzer’s available measurement range.
At this point, the CP 2M automatically ends the measurement cycle and switches to the
mirror-cleaning mode.
Subsequently, the analyzer starts the next measurement cycle.
