63!
Housing type
IP54
Digital
RS 485 /Modbus /RTU
Data ports
Analogue
4 – 20mА output, max. 400 Ohm,
Insulation 500 V
Power supply
20 – 27 V
Power consumption
≤ 25 W
Input cable threading
М 20 х 1.5
CP 2M
6.5 kg
CP 2M with SGA 003
25 kg
Weight
Power supply DR-60-24
≤ 0.69 kg
CP 2M
207 х 112 х 235 mm
CP 2M with SGA 003
510 x 510 x 172 mm
Dimensions
Power supply DR-60-24
80 х 90 х 60 mm
Environmental conditions required for operation
Ambient temperature
between +10° and +40 °С
2)
Relative humidity
≥ 98 % at +35 °С; the ratio between humidity and temperature
may not be such as to allow precipitation in the area
Barometric pressure
84 – 106.7 kPa
Maximum distance between the
CP 2M and the power supply
1000 m
3)
Service life
10 years
4)
Constant magnetic fields or alternating current fields that have a technical spectrum intensity of
more than 400 A /m is not permitted.
1)
– Sample gas flow rate units are Normal liters per minute (Nl/min) and are understood
to be measured at a gas pressure of 0.1 МPa
2)
– The temperature of the dew point analyzer, the gas preparation system, and
the sample extraction lines should be a minimum of 10 °C warmer than the expected
dew point temperature
3)
– The resistance of the power-supply conductor that connects the Cong Prima 2M to
its power supply should not exceed 2.5 Ohms.
4)
– The service life of the transducer (as a component of the CP 2M) is a minimum
of three years.
