Appendix E
SGA 003 gas preparations system
(Installation schematic)
Pos.
Designation
Description
Number
1
V15В-D-6M-R-S
Shutoff valve
1
2
THT-3R60-12-1-T
Seamless gravity-filter fall out tube
1
3
ВВ-13АН2КЕ99-053
Pressure regulator
1
4
VL82A-D-3M-S
Process switch
1
5
KRAY2.848.015-01
Dew point analyzer
(Cong Prima 2М)
1
6
Model 213.53.50
Manometer
1
7
V15В-D-6M-R-S
Shutoff valve
1
8
Model 213.53.50
Manometer
1
9
VMPL5.132.001
Intrinsically Safe Pressure Transmitter
1
10
DK 32
Float-type through-flow meter
1
11
DK 32
Float-type through-flow meter
1
12
DFBA-D-6M-SA
Quick-coupling connection for the
reference analyzer housing: gas inlet
1
13
DUB-6M-SA
Sleeve with mounting screw
1
14
DBL-6M-S
Mounting bracket with mounting screw
1
15
VMPL8.942.001
Backing plate
1
16
BPGC02.00-002 ВО
Terminal box
1
17
BPGC01.00-028 ВО
Terminal box
1
18
BPGC01.00-029 ВО
Terminal box
1
19
VL82A-D-6M-S
Ball valve
1
20
VMPL6.354.002
Foldout arm
1
21
VMPL5.863.002
Heating unit
1
22
VMPL8.658.001-02
Measurement chamber gas line: in
1
23
DT-3M-SA
T-connection
1
24
DT-6M-SA
T-connection
1
25
VMPL8.220.005
Pivot joint
1
26
Locking device
1
27
Mounting plate for the
reference instrument
1
