W'eau MiniPool YC-005TB1 - Exploded Diagram

14 pages

To Next Page

To Previous Page

- 9 -



7. Explodeddiagram



No. Name No. Name

1 Basetray 6 refrigerantvalve

2 Frontpanel 7 Titaniumheatexchanger

3 Backpillar 8 Evaporator

4 Controller 9 compressor

5 Fangrill 10 Topcover


