WABECO D3000 E - Lubrication

28
8. Startup and Maintenance
8.4 Lubrication
Prior to every putting into operation all lubricating points of the lathe must receive a grease for roller
bearings having commercial quality.
Both guiding bars have to be greased, too, preceding every putting into operation. The two dovetail
guides of the cross slide, the threaded spindles of the cross slide accessible from below, the feed
rod as well as the tailstock quill have to be greased at intervals of 100 service tours each using
lubricating oil.
When greasing make sure to put the slide of the cross slide to its hindmost position while extending
the tailstock quill to its foremost posision. Greasing the tailstock spindle is performed via the hollow
borehole within the quill.
RUECKW
VORW
0
AUS
NOT
appl
y
en
gi
ne o
i
l pr
i
or to
every putting into operation
apply grease prior to every
putting into operation
app
l
y grease pr
i
or to
every putting into operation
