Wabtec Microphor LF-310 - Parts Chart

Marine Head Manual P/N 24533 10 June 25, 2002
PARTS CHART
MODEL
PART
LF-210 China
Round
LF-210 China
Elongated
LF-219 China Round
Integral & Remote
LF-310 SS
Round
LF-320 SS
Round
A Toilet Shell 44032 - white
colors - see
chart
44010 - white
colors - see
chart
44151 - integral, white
44133 - remote, white
colors - see chart
93082 - shell
93084 - top shroud
93085 - bottom
shroud
colors - see chart
93008 - shell
colors - see
chart
B Toilet Lid 99064 - white
99073 - bolt down, white
colors - see chart
Not applicable
C Closet Screws
& Bolt Caps
93972 - white
colors - see chart
Not applicable
D Flush Activator 95002 - standard
95054 - positive
40046-5/40049-5 int, wht
40046-9/40049-9 int, blk
40046-7/40049-7 int, bone
95151 - remote
95561 - standard 95031 - standard
E Air/Water
Sequence Valve
39501 - no fittings
F Vacuum
Breaker
33559 - integral
33039 - remote
33421 - check valve
33039 - remote
96539 - integral 33039 - remote
G Bleed-Off Plug
Assembly
94598 30382-3 94598
H Valve Bracket 91897 - integral
20003 - remote
91866 - integral
20003 - remote
Not applicable 20003 - remote
I Hopper 90016-3 - rear
90008 - downward conversion kit
90016-3 - rear
95157 - downward hose
90039 - 3 rear
40050-3 Tank isolation valve
40050-3 tank isolation valve
27282 - Hopper Adaptor O-ring
J P-Trap, Rear
Discharge
96029
K Hopper
Mounting Assy
90899-5 00006 (4 each) and 00106 (4 each)
L Hopper Bleed
Valve
37548
M Hopper Screws 00064 (14 each) 00064 (10 each)
N Air Cylinder 94540
O Flapper Assy 90048
P Crank Assy 90042
Q Spud Assy 96347 95155 96579
R Water Supply
Tube
96012 - integral
35053 - remote
35484 - integral
35484 - remote
96002 96008
S Water
Connection
96387 N/A - integral
33352 - remote
96515 33352
T Air Fittings 30385 - 90E Elbow, 30365 - Straight
U Air Tubing/ft green - 35381, blue - 35382, red - 35383, yellow - 35384, white - 35385, black - 35419
V Hopper Gasket 27272 27270
W Air Supply Kit 93086 N/A
X Pressure Relief
Valve
37518
