Maintenance
9.3 Maintenance work
2
3
5. Insert the engine oil dipstick again.
6. Pull out the engine oil dipstick again.
7. Check engine oil fill level.
ð If the engine oil level is at the lower fill level limit 3, top up en-
gine oil if necessary, see Technical Data on page 51.
ð Fill engine oil to the upper fill level limit 2, do not overfill.
▪ Tighten the engine oil dipstick again.
9.3.5 Replacing engine oil
1
1. Remove dirt.
2. Provide a suitable container for draining the used oil.
3. Unscrew engine oil dipstick 1.
2
4. Unscrew the engine oil drain plug with sealing ring 2.
5. Allow the used oil to drain completely.
6. Tighten the engine oil drain plug with new sealing ring, tightening
torque 18 Nm.
7. Place the machine in a horizontal position.
8. Fill in new engine oil, see Checking and topping up engine oil level
on page 43.
9. Tighten the engine oil dipstick again.
9.3.6 Cleaning the deposit cup
3
B
1. Move the fuel cock3 into positionB.
