Maintenance
9.3 Maintenance work
9.3.8 Retightening and changing the V-belt
Carrying out preparations:
1. Place the machine on a level surface.
2. Decommissioning the machine.
3. Let the machine cool down.
Tighten the V-belt
1. Remove the V-belt guard.
2. Unscrew the screws of the exciter V-belt pulley.
3. Remove outer V-belt pulley half.
4. Remove the intermediate pulley.
5. Align and secure the removed intermediate pulleys and the outer V-
belt pulley half.
Information
When tightening, turn the V-belt pulley to prevent the V-belt from jam-
ming.
1. Tighten the screws.
2. Fit the V-belt guard, tightening torque 10Nm.
46 Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 |
Version: 5 | [en]
