Wacker Neuson BS-4

Technical Data
BS 13.3
47
[en] | 07/2022 | 5100060095 | BS-4 | Operator’s Manual
Type BS50-4As 11" BS50-4As 11"
Material number machine 5100030599 5100068310
Width (Ramming shoe) [mm] 280 280
Operating weight [kg] 65 65
Rated ouput [kW] 2,7 2,7
Rated speed [1/min] 4200 4200
Standard SAE J1349 SAE J1349
Engine type GXR 120 GXR 120
Oil specifications (Ramming system) SAE 10W-40 SAE 10W-40
Oil volume (Ramming system) [l] 0,7 0,7
Operating temperature range [°C] -10 – +40 SAE 10W-40
Storage temperature range [°C] -30 – +50 -30 – +50
Sound pressure level LpA [dB(A)] 93 93
Sound power level LWa measured [dB(A)] 105 105
Sound power level LWa guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 11 11
Measurement uncertainty of the total vibration value
ahv [m/s2]
1,9 1,9
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
Type BS60-4As 11" BS60-4As 11"
Material number machine 5100030606 5100037562
Material number engine 5100058517 5100058517
Number of strokes [1/min] 656 656
Impact force [kN] 18 18
Forward travel [m/min] 8,8 8,8
Length [mm] 673 673
Width [mm] 343 343
Height [mm] 965 965
Length (Ramming shoe) [mm] 340 340
Width (Ramming shoe) [mm] 280 280
Operating weight [kg] 72 72
Rated ouput [kW] 2,7 2,7
Rated speed [1/min] 4200 4200
Standard SAE J1349 SAE J1349
Engine type GXR 120 GXR 120
Oil specifications (Ramming system) SAE 10W-40 SAE 10W-40
Oil volume (Ramming system) [l] 0,9 0,9
Operating temperature range [°C] -10 – +40 -10 – +40
Storage temperature range [°C] -30 – +50 -30 – +50
Sound pressure level LpA [dB(A)] 92 92
Sound power level LWa measured [dB(A)] 105 105
Sound power level LWa guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 9,5 9,5
13
