Technical Data
13.4 Combustion engine
48
Operator’s Manual | BS-4 | 5100060095 | 07/2022 | [en]
Type BS60-4As 11" BS60-4As 11"
Material number machine 5100030606 5100037562
Measurement uncertainty of the total vibration value
ahv [m/s2]
1 1
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
Type BS60-4As 11"
Material number machine 5100051581
Material number engine 5100058517
Number of strokes [1/min] 656
Impact force [kN] 18
Forward travel [m/min] 8,8
Length [mm] 673
Width [mm] 343
Height [mm] 965
Length (Ramming shoe) [mm] 340
Width (Ramming shoe) [mm] 280
Operating weight [kg] 72
Rated ouput [kW] 2,7
Rated speed [1/min] 4200
Standard SAE J1349
Engine type GXR 120
Oil specifications (Ramming system) SAE 10W-40
Oil volume (Ramming system) [l] 0,9
Operating temperature range [°C] -10 – +40
Storage temperature range [°C] -30 – +50
Sound pressure level LpA [dB(A)] 92
Sound power level LWa measured [dB(A)] 105
Sound power level LWa guaranteed [dB(A)] 108
Vibration total value ahv [m/s2] 9,5
Measurement uncertainty of the total vibration value
ahv [m/s2]
1
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
13.4 Combustion engine
Engine manufacturer Honda
Material number engine 5100058517
Engine type GXR 120
Combustion processes four-stroke
Cooling Air
Cylinder 1
Cubic capacity [cm3] 121
Fuel type Gasoline
