T00823GB
44
Put the guard plate (13) on.
Screw on nuts (14) and tighten by hand.
To tighten the V-belt see “Tightening the V-belt /
Checking V-belt tension“.
Tighten the nuts (14) firmly with the combination
wrench.
IMPORTANT:
When you reposition the cutting attachment, the
direction of rotation of the cutting wheel changes.
Diamond cutting wheels must be installed in the
proper direction of rotation!
71
