9 Operation
26
100_0201_op_0003.fm
Note: Battery charger: Note the LEDs: all LEDs illuminate briefly until the oper-
ation indicator (blue LED) illuminates.
Rechargeable battery: Note the LED light progress bar. The LEDs indi-
cate the current charge situation of battery.
6. Check the charge situation of battery regularly.
9.3 Operation
Regularly check the charge situation of rechargeable battery during operation.
9.4 Decommissioning
If the rechargeable battery is completely charged, unplug the rechargeable bat-
tery from the battery charger and de-energize the battery charger.
Number of illuminating
LEDs of the rechargeable
battery
Significance
1 LED illuminates Charge situation of battery 0 - 20% - Charge the re-
chargeable battery.
2 LEDs are illuminated Charge situation of battery > 20%
3 LEDs are illuminated Charge situation of battery > 40%
4 LEDs are illuminated Charge situation of battery > 60%
5 LEDs are illuminated Charge situation of battery > 80%
6 LEDs are illuminated Charge situation of battery 100% - Cells are balanced.
6 LEDs are constantly illu-
minated
Charge situation of battery 100% - Rechargeable bat-
tery is completely charged.
all LEDs off Automatic shutdown after about 30 seconds
