10 Troubleshooting
100_0202_ts_0008.fm 57
1. Pull out jump-start and connect clamping tongs of the red jumper cable to the
jump-start.
2. Connect the second clamping pliers of the red jumper cable to the positive
terminal of the donor battery.
3. Connect the clamping pliers of the black jumper cable to the negative termi-
nal of the donor battery.
4. Connect the second clamping pliers of the black jumper cable to a ground
point of the machine e.g. on the engine block.
Help starting
5. Start engine.
If the engine does not switch on after 15 seconds, abort start attempt and
Wacker Neuson contact partner.
6. Let the engine run for several minutes.
Disconnect the jumper cables
7. Disconnect the clamping pliers of the black jumper cable from the ground
point of the machine.
8. Disconnect the clamping pliers of the red jumper cable from the donor bat-
tery.
9. Disconnect clamping tongs of the red booster cable from the jump-start and
press jump-start in.
10.Disconnect the clamping pliers of the red jumper cable from the positive ter-
minal of the donor battery.
Pos. Designation Pos. Designation
1 Jump-start 4 Negative terminal of the donor
battery
2 Negative terminal at ground
point
5 Positive terminal of the donor
battery
3 Black jumper cable 6 Red jumper cable
