14 Technical data
41
14.2 EH 65
*****Determined according to DIN EN ISO 5349.
Designation Unit EH 65/120
Item no. 0610421
Length x Width x Height
(without tool)
mm
(ft)
905 x 590 x 238
(3.0 x 1.9 x 0.8)
Weight kg (lb) 26 (57)
Rated voltage V 120 1~
Rated frequency Hz 60
Rated power consumption kW 1,9
Rated current
consumption
A15
Percussion rate rpm 1060
Single stroke energy J 65
Tool holder Hex 28x152
Special lubricating grease Retinax LX2 grease
Drive Three-phase AC motor
Class rating *
* According to DIN EN 61140.
ll
Protection class **
** According to DIN EN 60529.
IP2X
Sound power level L
WA
***
*** According to DIN EN ISO 3744.
dB(A) 107
Sound pressure level L
pA
at operator's station ****
dB(A) 99
Total vibration value of the
acceleration a
hv
*****
m/s
2
(in/s
2
)
5 (197)
Uncertainty of
measurement of the
vibration total value of the
acceleration ahv
m/s
2
(in/s
2
)
0,5 (20)
