Wacker Neuson G 25 User Manual

G 25 Schematics, Machines with Basler Controller
wc_tx003547gb_FM10.fm
203
24.2 AC Schematic Components:
Ref. Description Ref. Description
1 Lug safety limit switch 16 Generator
2 Mechanical lugs 17 Voltage regulator with 4A fuse
3 Plug 3 - line voltage inputs 18 Voltage adjustment rheostat
4 Shunt 19 Terminal block
5 Plug 5 - current transformer inputs 20 Exciter rotor windings
6 120V GFI receptacle 21 Exciter stator winding
7 120V 20A breaker 22 Rotor
8 240V 50A breaker 23 Rectifier (diodes)
9 240V 20A breaker (optional) 24 Main rotor winding
10 240V 50A receptacle 25 Main stator windings
11 240V 20A receptacle (optional) 26 Auxiliary stator winding
12 Engine control module 27 Stator
13 Main breaker 28 Exciter
14 Bus bar 29 Machine
15 Voltage selector switch — —
Wire Colors
BLK Black RED Red WHT White ORG Orange
GRN Green TAN Tan YEL Yellow — —
BLU Blue VIO Violet GRY Gray — —
