G 50 Schematics
wc_tx001582gb.fm
9 3
9.4 Engine Wiring Components
Ref. Description Ref. Description
1 Electronic control unit 15 Starter motor
2 Plug 1 - engine sender inputs 16 Alternator
3 Plug 2 - contact inputs 17 Mechanical lugs
4 Remote start-Off-Start/Run switch 18 Main circuit breaker
5 Relay - engine outputs 19 Fuel level indicator
6 Hour meter 20 Lug door interlock switch
7 10A fuse 21 Bond bar
8 7.5A fuse 22 Shunt trip relay
9 Intake heater 23 Battery disconnect (optional)
10 Intake heater relay 24 Plug 4 - E-stop & contact outputs
11 Starter relay 25 Oil pressure indicator
12 Emergency stop switch 26 Water temperature indicator
13 Remote start terminals 27 Fuel throttle
14 Battery
Wire Colors
BLK Black RED Red WHT White ORG Orange
GRN Green TAN Tan YEL Yellow
BLU Blue VIO Violet GRY Gray
